PTVS3V3S1UR瞬變二極管400W 貼片SOD123封裝
TVS二極管, PTVS3, 單向, 3.3 V, 8 V, SOD-123, 2 引腳
產品信息
TVS極性:單向
反向關態電壓 Vrwm:3.3V
鉗位電壓 最da:8V
二極管封裝類型:SOD-123
針腳數:2引腳
擊穿電壓范圍:5.2V-6V
峰值脈沖功率耗散:400W
汽車質量標準: AEC-Q101
產品概述
PTVSxS1UR系列單向扁平引線薄型表面安裝瞬態電壓抑制二極管, 專為保護瞬態過壓而設計. 3.3至64V反向隔離電壓范圍 (VRWM).
400W額定峰值脈沖功率 (PPPM)
350W額定峰值脈沖功率 (PPPM), 適用于3V3
0.001μA反向電流 (IRM)
應用：
車用, 車用, 工業
PTVS5V0S1UR,115
TVS二極管, PTVS5, 單向, 5 V, 9.2 V, SOD-123, 2 引腳
PTVS3V3S1UR A1 PTVS20VS1UR AL
PTVS5V0S1UR A2 PTVS22VS1UR AM
PTVS6V0S1UR A3 PTVS24VS1UR AN
PTVS6V5S1UR A4 PTVS26VS1UR AP
PTVS7V0S1UR A5 PTVS28VS1UR AR
PTVS7V5S1UR A6 PTVS30VS1UR AS
PTVS8V0S1UR A7 PTVS33VS1UR AT
PTVS8V5S1UR A8 PTVS36VS1UR AU
PTVS9V0S1UR A9 PTVS40VS1UR AV
PTVS10VS1UR AA PTVS43VS1UR AW
PTVS11VS1UR AB PTVS45VS1UR AX
PTVS12VS1UR AC PTVS48VS1UR AY
PTVS13VS1UR AD PTVS51VS1UR AZ
PTVS14VS1UR AE PTVS54VS1UR B1
PTVS15VS1UR AF PTVS58VS1UR B2
PTVS16VS1UR AG PTVS60VS1UR B3
PTVS17VS1UR AH PTVS64VS1UR B4
PTVS18VS1UR AK - -
